AUTO26 Debug Probe with Cortex-M License
AUTO26 Debug Probe with Cortex-M License
AUTO26 Debug Probe with debug license
to debug Cortex-M cores and SecurCore SC000/SC300,
via JTAG, cJTAG (IEEE 1149.7), or Serial Wire Debug (SWD).
We recommend ordering the IDC20A Debug Probe LA-3254 instead
(for Cortex-M based SoCs) because
IDC20A supports a wider voltage range for the debug signals, and
IDC20A supports a wider range of subcore architectures.
Includes licenses to debug and trace
Cortex-M cores and SecurCore SC000/SC300,
as well as debug GTM and IPU cores.
Includes TRACE32 software for Windows, Linux and macOS
on DVD or via download.
Requires TRACE32 R.2022.09-SP2 or newer.
Requires any PowerDebug with USB 2/USB 3/Ethernet and newer.
(Not supported with LA-7702 and LA-7704)
Voltage range 1.8V to 5.0V.
Technical Information
Technical Data
INCLUDED PRODUCTS:
Extend the AUTO26 Debug Probe with Cortex-M License
Allowed Licenses
The following licenses can be added to the product to support debug and/or tracing of other core architectures.
- LA-3750A ARC® 32-bit Debug License (Nodelocked)
- LA-2760A dsPIC Debug License (Nodelocked)
- LA-3732A XC800 Debug License (Nodelocked)
- LA-3730A MicroBlaze Debug License (Nodelocked)
- LA-7960X License for Multicore Debugging
- LA-7838A C6000 Debug License (Nodelocked)
- LA-7843X Armv7-A/R Debug License (Nodelocked) Ext.
- LA-7753A MPC5xxx Debug License (Nodelocked)
- LA-3760A Xtensa® Debug License (Nodelocked)
- LA-3711A Ceva-X Debug License (Nodelocked)
- LA-3719A RH850 Debug License (Nodelocked)
- LA-7847A C2000 Debug License (Nodelocked)
- LA-2540A RISC-V 32-bit Debug License (Nodelocked)
- LA-2756A JTAG Debugger for PRU Add.
- LA-2759A C7000 Debug License (Nodelocked)
- LA-7756A TriCore Debug License (Nodelocked)
- LA-3743X Armv8/v9-A/R Debug License (Nodelocked) Ext.
- LA-2541A RISC-V 64-bit Debug License (Nodelocked)
- LA-2900X License for PIL Simulation (Cable)
